Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 200mm -
Travel Rear 205mm -
Fork RockShox BoXXer Ultimate
-
Groupset Saint -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Gravity DH 29 / Think Link suspension system, 205 mm rear travel, internal routing, ISCG 05, 12x150 mm thru axle
Suspension Fork
ROCK SHOX BoXXer Ultimate (29) Boost, 200 mm, DebonAir / Charger 2 RC2 / Maxle Stealth 20 mm thru axle
Rear Shock
ROCK SHOX Super Deluxe Coil Ultimate DH RC (250x75 mm)
Drivetrain
Rear Derailleur
SHIMANO Saint M820 (direct mount)
Front Derailleur
chain guide MOZARTT HXR, ISCG 05
Shift Levers
SHIMANO Saint SL-M820 Rapidfire Plus
Cassette
SHIMANO CS-HG500-10 (11-25T)
Crank
SHIMANO Saint M825 Hollowtech II (34T) - length 165 mm
Bottom Bracket
SHIMANO Press-Fit BB71-41A
Chain
KMC X10 EL (104 links)
Pedals
plastic
Wheels
Front Hub
NOVATEC DH Disc (20x110 mm / 12x150 mm / 32 holes)
Rear Hub
NOVATEC DH Disc (20x110 mm / 12x150 mm / 32 holes)
Rims
KLS Brave 3 Disc 622x30 (32 holes)
Spokes
stainless steel black
Tires
SCHWALBE Magic Mary 60-622 (29x2.35) SnakeSkin, Tubeless Easy, ADDIX Soft, folding
Brakes
Brakes
SHIMANO Saint M820 Hydraulic Disc
Brake Levers
SHIMANO Saint BL-M820
Cockpit
Stem
RACE FACE Atlas DM - direct mount / bar bore 31.8 mm x 50/30
Handlebar
RACE FACE Atlas RiseBar - diam 31.8 mm / rise 13 mm / width 785 mm
Grips
KLS Poison
Seat
Saddle
fi’zi:k Taiga, S-alloy rails
Seatpost
RACE FACE Chester - diam 30.9 mm / length 325 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 29" | 29" |
