Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Crossforce Lite - tapered HT, internal routing, integrated kickstand mount
Suspension Fork
SR SUNTOUR NEX RL DS, 63 mm, coil / Speed Lockout
Drivetrain
Rear Derailleur
SHIMANO Cues U3020 (direct mount)
Front Derailleur
SHIMANO Cues U4010-L (34.9 mm)
Shift Levers
SHIMANO Cues SL-U4010-9R Rapidfire Plus
Cassette
SHIMANO Linkglide CS-LG300-9 (11-36T)
Crank
SHIMANO Cues U4010-2 (46x30T) - length 175 mm
Bottom Bracket
SHIMANO BB-UR400
Chain
SHIMANO Linkglide CN-LG500 (114 links)
Pedals
alloy
Wheels
Front Hub
SHIMANO TX505 Disc Center Lock (32 holes)
Rear Hub
SHIMANO TX505 Disc Center Lock (32 holes)
Rims
KLS Draft 23 Disc 622x23 (32 holes)
Spokes
stainless steel black
Tires
INNOVA 44-622 (700x42C)
Brakes
Brakes
SHIMANO MT200 hydraulic disc
Brake Levers
SHIMANO BL-MT200
Cockpit
Stem
KLS Advanced - diam 28.6 mm / bar bore 31.8 mm / 7° / length 90 mm
Handlebar
KLS CRX 70 RiseBar - diam 31.8 mm / rise 25 mm / width 640 mm (M), 660 mm (L)
Grips
KLS Token 2Density
Seat
Saddle
KLS
Seatpost
KLS Active - diam 30.9 mm / length 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 700 | 700 |
