Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Tektro Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Gravel Concept Aluminium alloy Disc / tapered HT, flat mount disc brake, internal routing / 12 mm thru axle
Suspension Fork
KELLYS Carbon Disc, 1.5 tapered steerer / flat mount disc brake / 12 mm thru axle
Drivetrain
Rear Derailleur
SHIMANO Claris R2000 (direct mount)
Front Derailleur
SHIMANO Claris R2000 (braze on)
Shift Levers
SHIMANO Claris ST-R2000 Dual Control
Cassette
SHIMANO CS-HG50-8 (11-32T)
Crank
SHIMANO Claris R2000 (50x34T) - length 170 mm (S - M), 175 mm (L)
Bottom Bracket
SHIMANO BB-RS500
Chain
KMC Z8 (112 links)
Wheels
Front Hub
NOVATEC Disc (32 holes)
Rear Hub
NOVATEC Disc (32 holes)
Rims
KLS Grind Disc 622x17 (32 holes / eyelets)
Spokes
stainless steel black
Tires
SCHWALBE Smart Sam Performance 42-622 (700x40C) ADDIX
Brakes
Brakes
TEKTRO Spyre Mechanical Disc
Brake Levers
SHIMANO Claris ST-R2000 Dual Control
Cockpit
Stem
KLS Active - diam 28.6 mm / bar bore 31.8 mm / 6° / length 90 mm (S), 100 mm (M), 110 mm (L), 120 mm (XL)
Handlebar
GravelBar - diam 31.8 mm / width 400 mm (S), 420 mm (M), 440 mm (L), 460 mm (XL)
Grips
KLS bar tape
Seat
Saddle
WTB Volt
Seatpost
KLS Active Road - diam 30.9 mm / length 350 mm (S), 400 mm (M - XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
