Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Tektro Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Gravel Concept Aluminium alloy Disc / tapered HT, flat mount disc brake, internal routing / 12 mm thru axle
Suspension Fork
KELLYS Carbon Disc, 1.5 tapered steerer / flat mount disc brake / internal routing / 12 mm thru axle
Drivetrain
Rear Derailleur
SHIMANO Claris R2000 (direct mount)
Front Derailleur
SHIMANO Claris R2000 (braze on)
Shift Levers
SHIMANO Claris ST-R2000 Dual Control
Cassette
SHIMANO CS-HG50-8 (11-32T)
Crank
SHIMANO Claris R2000 (50x34T) - length 170 mm (S - M), 175 mm (L)
Bottom Bracket
SHIMANO BB-RS500
Chain
KMC Z8 (112 links)
Wheels
Front Hub
NOVATEC Disc Center Lock (28 holes)
Rear Hub
NOVATEC Disc Center Lock (28 holes)
Rims
KLS Grind 25 Disc 622x25 (28 holes)
Spokes
stainless steel black
Tires
SCHWALBE Smart Sam Performance 42-622 (700x40C) ADDIX
Brakes
Brakes
TEKTRO Spyre Mechanical Disc
Brake Levers
SHIMANO Claris ST-R2000 Dual Control
Cockpit
Stem
KLS Active - diam 28.6 mm / bar bore 31.8 mm / 6° / length 90 mm (S), 100 mm (M), 110 mm (L), 120 mm (XL)
Handlebar
GravelBar - double butted, diam 31.8 mm / width 400 mm (S), 420 mm (M), 440 mm (L), 460 mm (XL)
Grips
KLS bar tape
Seat
Saddle
WTB Volt
Seatpost
KLS Active Road - diam 30.9 mm / length 350 mm (S), 400 mm (M - XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
