Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS Alutec RRC 29" - Race Ready Concept
Suspension Fork
SR SUNTOUR XCR32 ATB Air RLR DS (29"), 100 mm, air / Remote Speed Lockout
Drivetrain
Rear Derailleur
SHIMANO Deore M6100 (direct mount)
Shift Levers
SHIMANO Deore SL-M6100-R Rapidfire Plus
Cassette
SHIMANO CS-M6100-12 (10-51T)
Crank
SAMOX (34T) - length 170 mm (S - M), 175 mm (L - XL)
Bottom Bracket
cartridge (122 mm)
Chain
KMC X12 (116 links)
Pedals
plastic
Wheels
Front Hub
SHIMANO TX505 / Deore MT401 Disc Center Lock (32 holes)
Rear Hub
SHIMANO TX505 / Deore MT401 Disc Center Lock (32 holes)
Rims
KLS Draft 23 Disc 622x23 (32 holes)
Spokes
stainless steel black
Tires
KENDA Booster 56-622 (29" x 2.20)
Brakes
Brakes
SHIMANO MT200 Hydraulic Disc
Brake Levers
SHIMANO BL-MT200
Cockpit
Stem
KLS Active - diam 28.6 mm / bar bore 31.8 mm / length 60 mm (S - M), 70 mm (L - XL)
Handlebar
KLS Active FlatBar - diam 31.8 mm / width 680 mm (S), 720 mm (M - XL)
Grips
KLS Advancer 2Density
Seat
Saddle
KLS Sentinel 2
Seatpost
KLS Active - diam 30.9 mm / length 350 mm (S), 400 mm (M - XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
