Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KELLYS KLC 29" - Lady Sport Geometry
Suspension Fork
SR SUNTOUR XCM HLO DS (29"), 100 mm, coil / Speed Lockout
Drivetrain
Rear Derailleur
SHIMANO Altus M2000 (direct mount)
Front Derailleur
SHIMANO Altus M2020 (34.9 mm)
Shift Levers
SHIMANO Altus SL-M2010-9 Rapidfire Plus
Cassette
SHIMANO CS-HG200-9 (11-34T)
Crank
SHIMANO MT101-2 (36x22T) - length 175mm
Bottom Bracket
cartridge (122 mm)
Chain
KMC X9 (110 links)
Pedals
alloy
Wheels
Front Hub
SHIMANO TX505 Disc Center Lock (32 holes)
Rear Hub
SHIMANO TX505 Disc Center Lock (32 holes)
Rims
KLS Draft Disc 622x21 (32 holes)
Spokes
steel
Tires
IMPAC Ridgepac or WTB Nano 54-622 (29"x2.10)
Brakes
Brakes
SHIMANO MT200 hydraulic disc
Brake Levers
SHIMANO BL-MT200
Cockpit
Stem
KLS Active - diam 28.6 mm / bar bore 31.8 mm / 8° / length 75 mm (M), 90 mm (L)
Handlebar
KLS Active RiseBar - diam 31.8mm / rise 18mm / width 620mm (M), 660mm (L)
Grips
KLS Advancer 2Density
Seat
Saddle
KLS Ebony Women
Seatpost
KLS Active - diam 30.9 mm / length 350 mm (S), 400 mm (M - L)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Wheels | 29" | 29" |
