Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Fork Manitou Mastodon Pro -
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KHS High Modulus MSD Full Carbon w/1.5 Taper Headtube, Disc Only, Internal Cable Routing
Suspension Fork
High Modulus Full Carbon Straight Blade, w/1.5 Taper 15QR, or Manitou Mastodon Pro 100mm or Wren Fork Option
Drivetrain
Rear Derailleur
Shimano New XT RD-M8100
Front Derailleur
n/a
Shift Levers
Shimano New XT, SL-M8100, 12s, Trigger, Right Only
Cassette
Shimano CS-M7100, 10-51T, 12-Speed
Crank
FSA Comet 2-pc w/MegaExo, 30T Mega Tooth, S:170, M-L:175
Bottom Bracket
FSA MegaExo Outboard Cartridge Bearing
Chain
Shimano CN-M7100
Pedals
n/a
Wheels
Front Hub
Aluminum Disc, Full CNC, Sealed Bearing, 15mm x 150mm Thru-Axle
Rear Hub
Powerway Aluminum Disc, Forged, Sealed Bearing, Cassette, 12x197 Thru-Axle
Rims
Sun Mulefut SL80, Tubeless-Ready, 26x32H
Spokes
14G Black Stainless, 32x32, w/Aluminum Nipples
Tires
Maxxis Colossus, 26 x 4.8”, 120TPI, Tubeless-Ready
Brakes
Brakes
Shimano MT420 4-Piston Hydraulic Disc, 180/160mm Rotors, Wave ‘12’
Brake Levers
Shimano M4100, I-Spec EV
Cockpit
Stem
FSA Grid 3D Forged 35x50mm
Handlebar
FSA Grid 35mm, 760mm x 20mm
Grips
Q2 Lock-on
Headset
FSA Orbit C40-ACB, N.42/CF/ACB, 1-1/8”~1.5” Integrated, Carbon Cap
Seat
Saddle
WTB Volt Medium SL
Seatpost
Kind Shock Rage-i, Integra w/Remote, Travel Adjust, S:100x345, M:125x390, L-XL:150x445
