Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Suntour XCR 34
-
Groupset Deore, Suntour -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4-Bar Horst Link 29/650B+ 130mm, 6061 Aluminum w/Custom Formed Double Butted T/T & D/T, 1.5 Taper, 12 x 148 Rear Axle, w/Replaceable Derailleur Hanger, Internal Cable
Suspension Fork
SR XCR34 Boost, LOR Air, S:27.5, M-XL:29”, 140mm, 34mm Stanchions, Aluminum Steerer, Magnesium Lowers, Hydraulic Damp, External rebound, Lock-Out, 1.5 Taper, 15QR x 110mm
Rear Shock
X-Fusion 02 Pro RL, Air, Ext Rebound, Lock-Out
Drivetrain
Rear Derailleur
Shimano Deore, RD-M6100
Front Derailleur
n/a
Shift Levers
Shimano Deore, SL-M6100, 12s, Trigger, Right Only
Cassette
Shimano CS-M6100, 10-51T, 12-Speed
Crank
SR Zeron, 2-pc, Boost, 30T Zig/Zag, S:170, M-XL:175
Bottom Bracket
SR Outboard Cartridge Bearing
Chain
Shimano CN-M6100
Pedals
n/a
Wheels
Front Hub
Formula Sealed Bearing Aluminum Disc, 15mm, 110mm Boost
Rear Hub
Formula Sealed Bearing Aluminum Disc, Cassette, 12 x 148mm Boost
Rims
WTB ST=S:i35, M-XL:i29 TCS, Disc, Double Wall, 32H, Tubeless-Ready
Spokes
14G Stainless Black w/Aluminum Nipples, 32x32
Tires
Kenda Regolith Pro, S:27.5 x 2.6”, M-XL:29 x 2.4”, 120TPI, Folding, Tubeless-Ready
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180/160mm Rotors Wave 12
Brake Levers
Shimano MT200
Cockpit
Stem
35mm Aluminum 3D Forged, Threadless 4-bolt
Handlebar
Aluminum 35mm Riser, 780 x 15mm
Grips
Q2 Lock-on
Headset
FSA Orbit 1.5E, Zero Stack, 1-1/8”~1.5
Seat
Saddle
WTB Volt Medium SL
Seatpost
Kind Shock Exa-Form KSP-900-i, Integra w/Remote, Travel Adjust, 31.6mm
Model Overview
5500 is part of the Khs 5500 model. KHS released 5 bikes variations of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, KHS 5500 price was 2959$. Doing a quick comparison, we notice that 5500 price is 7.13% more expensive than the average cost of a Trail bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
The 5500 comes factory-installed with the Suntour XCR 34 fork. This has a travel range of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
5500 has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
KHS 5500 bike has the X-Fusion 02 Pro RL model installed, and has a travel of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on 5500 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. KHS 5500 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
KHS 5500 2022 is available in one size only. In short, make sure you double-check if it fits you.
Dropper post
A dropper post is included with the 5500. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
