Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Travel Rear 130mm -
Fork Suntour Zeron
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4-Bar Horst Link 29/650B+ 130mm, 6061 Aluminum w/Custom Formed Double Butted T/T & D/T, 1.5 Taper, 12 x 148 Rear Axle, w/Replaceable Derailleur Hanger, Internal Cable
Suspension Fork
SR Zeron 35, EQ RC Boost, Air, S:27.5”, M-L:29”, 140mm, 34mm Stanchions, Aluminum Steerer, Magnesium Lowers, Hydraulic Damp, External rebound, Lock-Out, 1.5 Taper, 15QRx110mm
Rear Shock
X-Fusion 02 Pro RL, Air, Ext Rebound, Lock-Out, 200x51
Drivetrain
Rear Derailleur
Shimano Deore RD-M6100
Front Derailleur
n/a
Shift Levers
Shimano Deore, SL-M6100, 12s, Trigger, Right Only
Cassette
Shimano CS-M6100, 10-51T, 12-Speed
Crank
FSA Comet, 2-pc., 30T Megatooth, Boost, S:170, M-XL:175
Bottom Bracket
FSA MegaExo Outboard Cartridge Bearing
Chain
Shimano CN-M6100
Pedals
n/a
Wheels
Front Hub
Formula Sealed Bearing Aluminum Disc, 15mm, 110mm Boost
Rear Hub
Formula Sealed Bearing Aluminum Disc, Cassette, 12x148mm Boost
Rims
WTB ST= S:i35, M-L:i29 TCS, Disc, Double Wall, 32H, Tubeless-Ready
Spokes
14G Black w/Aluminum Nipples, 32x32
Tires
Kenda Regolith Pro, S:27.5 x 2.6”, M-L:29 x 2.4”, 120TPI, Folding, Tubeless-Ready
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 203/180mm Rotors Wave ‘12’
Brake Levers
Shimano MT200
Cockpit
Stem
35mm Clamp Diameter, Aluminum 3D Forged, Threadless 4-bolt, 45mm
Handlebar
Aluminum 35mm Riser, 780 x 15mm
Grips
Q2 Lock-on
Headset
FSA Orbit 1.5E, Zero Stack, 1-1/8”~1.5
Seat
Saddle
WTB Volt Medium SL
Seatpost
Kind Shock Exa-Form KSP-900-i, Integra w/Remote, Travel Adjust, 31.6mm, S:110x345, M-L:125x395
