Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Travel Front 120mm -
Fork Marzocchi Bomber Z2
-
Groupset SLX, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 520 CrMo Double Butted T/T 38.1mm, D/T 40mm, S/T 32.4mm
Suspension Fork
29” Marzocchi Z2 AIR, 120mm, Ext Rebound Adj, Sweep Adj to Lock, 1.5 Taper Aluminum Steerer, 15mm x 110 Boost
Drivetrain
Rear Derailleur
Shimano SLX, RD-M7100
Front Derailleur
n/a
Shift Levers
Shimano Deore SL-M6100, Right Only, I-Spec EV
Cassette
Shimano Deore 10-51T, 12-Speed
Crank
KHS 2-pc Forged 200mm w/Outboard Bearing, 32T
Bottom Bracket
Outboard Cartridge Bearing
Chain
Shimano CN-M6100
Pedals
Resin ATB Platform w/DU Bearings
Wheels
Front Hub
Shimano HB-MT410, CenterLock Disc, 15mm x 110mm, Boost
Rear Hub
Shimano FH-MT410-B Disc Cassette, 12 x 148mm, Boost
Rims
WTB ST-I29 TCS, Disc, Double Wall, 29x36H, Tubeless-Ready
Spokes
14G Black w/Aluminum Nipples, 36x36
Tires
Kenda Booster Pro, 120TPI Folding, Tubeless-Ready, 29x2.6
Brakes
Brakes
Shimano MT420 4-Piston Hydraulic Disc, 203mm, 180mm RT64 CenterLock Rotors
Brake Levers
Shimano M4100, I-Spec EV
Cockpit
Stem
35mm Aluminum 3D Forged, Threadless 4-bolt, 120mm
Handlebar
Aluminum 35mm Riser, 800 x 30mm
Grips
WTB Moto Dual Clamp
Headset
FSA 57EP, Zero Stack, 1-1/8”~1.5
Seat
Saddle
WTB Volt Wide SL
Seatpost
Aluminum Micro-Adjust, 31.6x400mm
