Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney -
Suspension Rigid -
Motor 250W 45Nm hub-drive -
Battery Lithium 36V x 12.8Ah, 460Wh -
Drivetrain 1 × 7 -
Brakes Promax Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
24E 6061 Aluminum Low-Step Custom Formed, Cable Guide
Suspension Fork
Full Hi-Tensile steel w/forged drop-outs
Drivetrain
Rear Derailleur
Shimano Tourney TY500D
Front Derailleur
n/a
Shift Levers
Shimano Revo Twist
Cassette
Shimano Tourney, Freewheel, 14-28, 7-Speed
Crank
Prowheel, Aluminum, 44T Black, 165mm
Chain
KMC Z-7RB
Pedals
Wellgo Platform
Wheels
Front Hub
KT Aluminum QR
Rear Hub
Zhang Yíng Motor
Rims
Weinmann SP-17 Aluminum Double Wall, 24x1.5
Spokes
FT:14G Stainless Black RR:13G Stainless Black, 36x36
Tires
24 x 1.50” Black, 60TPI 100PSI
Brakes
Brakes
Promax, TX-117L, Linear Pull
Brake Levers
Bengal Aluminum Linear Pull Trekking 3 Finger w/Sensor Control
Cockpit
Stem
Aluminum Quill, 60mm
Handlebar
Aluminum 100 rise 15 degree, 620mm
Grips
Comfort Kraton
Headset
Threaded 1-1/8”, Zero stack
Seat
Saddle
KHS Sport Dual Density
Seatpost
Promax, Aluminum, Micro-Adjust, 27.2x300mm
Motor & Battery
Motor
Zhang Yíng Motor 36V x 250W, 45Nm, Class II
Battery
Lithium 36V x 12.8Ah, 460Wh
