Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Altus -
Suspension Rigid -
Motor Bafang 500W 45Nm hub-drive -
Battery Lithium 48V x 10.5Ah, 504Wh -
Drivetrain 1 × 8 -
Brakes Tektro Drum
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 Double Butted CrMo Tubing w/Carrier Bosses
Suspension Fork
Full CrMo Unicrown, Low-rider and Fender Bosses
Drivetrain
Rear Derailleur
Shimano Altus M310
Front Derailleur
n/a
Shift Levers
Shimano Twist
Cassette
Shimano CS-HG31-8, 11-32T, 8-Speed
Crank
Samox Forged, 36T w/Guard, 175mm
Chain
KMC E8
Pedals
Wellgo Platform w/Non-slip Tread, DU Bearings
Wheels
Front Hub
Aluminum QR
Rear Hub
Bafang, Drum Motor
Rims
Weinmann ZAC2000, 700x36H, Double Wall w/CNC Side Wall
Spokes
Front 14G Black 36H; Rear 13G Black 36H
Tires
Kenda Kwick Journey, 700 x 35c w/K-Shield Anti-Puncture, 60TPI
Brakes
Brakes
Tektro Aluminum Linear Pull
Brake Levers
Bengal Aluminum Linear Pull Trekking 3-Finger w/Sensor Control
Cockpit
Stem
KHS Aluminum Threadless, 25 degree, Ladies: 70mm, Mens: 80mm
Handlebar
Aluminum Trekking, 30mm x 630mm, 31.8mm
Grips
Velo Dual Density
Headset
FSA Threadless 1-1/8”, Zero Stack
Seat
Saddle
KHS Ultra Comfort
Seatpost
Aluminum Micro-Adjust, 27.2x350mm
Motor & Battery
Motor
Bafang RMG020-500DC, 48V x 500W, 45Nm, Class II
Battery
Lithium 48V x 10.5Ah, 504Wh
