Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 50mm -
Fork Suntour NEX
-
Groupset CUES -
Suspension Hardtail -
Motor Bafang 500W 45Nm hub-drive -
Battery Lithium 48V x 10.5Ah, 504Wh -
Drivetrain 1 × 9 -
Brakes Drum
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum w/Custom Formed T/T w/C/S Disc Mount, w/Replaceable Derailleur Hanger
Suspension Fork
SR NEX, 50mm
Drivetrain
Rear Derailleur
Shimano Cues
Front Derailleur
n/a
Shift Levers
Shimano Cues Trigger
Cassette
Shimano CS-LG300-9, 11-36, 9-Speed
Crank
Forged, 36T w/Guard, 170mm
Chain
KMC E500
Pedals
Resin ATB Platform w/DU Bearings
Wheels
Front Hub
Aluminum QR
Rear Hub
Bafang, Drum Motor
Rims
Weinmann XTB26 Aluminum, 700c x 36H, Double wall
Spokes
Front 14G Black 36H; Rear 13G Black 36H
Tires
Kenda Kwick Bitumen, 700 x 40c, 30TPI
Brakes
Brakes
Bengal Cable Disc, 180mm Rotors Wave 12
Brake Levers
Bengal Aluminum Linear Pull w/Sensor Control
Cockpit
Stem
Aluminum 3D Forged, Threadless 4-bolt, 7-degree, 31.8mm, S: 60mm, M-L: 80mm
Handlebar
Aluminum, 31.8mm, 680x30mm
Grips
KHS Sport, Dual Compound
Headset
Threadless 1-1/8”, Zero Stack
Seat
Saddle
KHS Sport, Dual Density
Seatpost
Aluminum Micro-Adjust, 27.2x350mm
Motor & Battery
Motor
Bafang RMG020-500DC, 48V x 500W, 45Nm, Class II
Battery
Lithium 48V x 10.5Ah, 504Wh
