Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney -
Suspension Rigid -
Drivetrain 2 × 7 -
Brakes Tektro Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Disc Design, 6061 Aluminum w/Custom Formed Double Butted T/T & D/T, Internal Cable, Flat Mount Disc, Replaceable Derailleur Hanger
Suspension Fork
Hi-Tensile Unicrown, Flat Mount Disc, Straight Blades
Drivetrain
Rear Derailleur
Shimano Tourmey RD-A070
Front Derailleur
Shimano Tourney FD-A070, 31.8mm
Shift Levers
Shimano Tourney STI, ST-A070
Cassette
Shimano Cassette, HG20-7, 12-28T, 7-Speed
Crank
Prowheel Alloy, 3-pc, 50-34T, XS-S:165, M-XL:170, Ladies: XXS-XS:165, S:170
Bottom Bracket
FSA Cartridge Bearing
Chain
KMC Z8.3
Pedals
Wellgo Resin w/Aluminum Cage & DU Bearing
Wheels
Front Hub
KK Aluminum Disc, QR
Rear Hub
KK Aluminum Disc QR, Cassette
Rims
Weinmann XP-24 Aluminum Double Wall
Spokes
14G Black, 32x32
Tires
Kenda K-193 Kwest Road, 700x28C
Brakes
Brakes
Tektro MD-C310, Flat Mount Road Cable Disc Brake w/160mm Rotors
Brake Levers
Shimano STI, ST-A070
Cockpit
Stem
Aluminum 3D Forged, Threadless 4-bolt, 7-degree, 31.8mm XXS: 80mm, XS:90mm, S-L:100mm, XL:110mm
Handlebar
FSA Omega Compact Bend, 31.8, XXS: 380, XS-S: 400, M: 420, L-XL: 440
Headset
FSA Integrated Cartridge Bearing
Seat
Saddle
DDK Road Padded
Seatpost
KHS Aluminum Micro-Adjust, 27.2x350mm
