Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Tektro Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KHS Disc, Full MSD Carbon Monocoque w/Replaceable Derailleur Hanger, Internal cable routing, Flat Mount Disc, 12x142mm Thru-Axle
Suspension Fork
KHS Performance Disc, Full Carbon, Flat Mount w/12mm Thru-Axle
Drivetrain
Rear Derailleur
Shimano Sora RD-R3000-SS
Front Derailleur
Shimano Sora FD-R3000
Shift Levers
Shimano Sora ST-R3000
Cassette
Shimano CS-HG200-9, 11-32T, 9-Speed
Crank
FSA Omega Compact, 2pc Forged w/Outboard Bearing, 50/34, XS:165, S:170, M-ML:172.5, L-XL:175
Bottom Bracket
FSA Mega EXO Outboard Cartridge Bearing
Chain
KMC Z9 w/Missing Link
Pedals
n/a
Wheels
Front Hub
Formula RX512 Aluminum Disc, 12mm QR
Rear Hub
Formula RX142 Aluminum Disc, Cassette, 12mm QR
Rims
Alex GD24P, Disc Double Wall
Spokes
14G Stainless Black, 24x28
Tires
Kenda Kriterium, 700x28C, 60TPI Folding
Brakes
Brakes
Tektro MD-C550 Dual Piston, Flat Mount Road Cable Disc Brake w/160mm Rotors
Brake Levers
Shimano Sora ST-R3000
Cockpit
Stem
Aluminum 3D Forged, Threadless 4 Bolt, 31.8, XS-S:90mm, M-ML:100mm, L-XL:110mm, Ladies:80mm
Handlebar
FSA Omega Compact, 31.8, XS-S: 40cm, M-M/L:42cm, L-XL:44cm, Ladies: 38cm
Headset
FSA Integrated 69 SRS, Aluminum Cap
Seat
Saddle
KHS Team Road Cut Out
Seatpost
Aluminum Micro-Adjust, 27.2mm
