Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Ultegra, Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano Ultegra Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KHS Toray High Modulus T800SC(60%)/M40JB(40%) Full Carbon Monocoque, Replaceable Derailleur Hanger, Front/Rear Thru-Axle
Suspension Fork
KHS Pro Full Carbon, 1.5 Taper
Drivetrain
Rear Derailleur
Shimano Ultegra, DI2 RD-R8150
Front Derailleur
Shimano Ultegra, DI2 FD-R8150
Shift Levers
Shimano Ultegra, DI2 ST-R8170, Hydraulic
Cassette
Shimano Ultegra CS-R8100, 11-34, 12-Speed
Crank
Shimano Ultegra FC-R8100, 52/36T, Mid Compact, XS:165, S:170, M-ML:172.5, L-XL:175
Bottom Bracket
Shimano Outboard Bearing
Chain
Shimano Ultegra, CN-M710D, 12-Speed
Pedals
n/a
Wheels
Front Hub
Shimano RS-710 Disc, 12x100mm
Rear Hub
Shimano RS-710 Disc, 12x142mm
Rims
Shimano RS-710 Disc, Tubeless Ready, Full Carbon, C46
Spokes
Shimano RS-710, 24x24
Tires
Kenda Valkyrie, 700x28C, 120TPI, Folding, RC3, KSCT
Brakes
Brakes
Shimano Ultegra, BR-R8170 Hydraulic Disc, Flat Mount w/160mm Shimano CTR Lock Ice Tech Rotors
Brake Levers
Shimano Ultegra ST-8170 Hydraulic
Cockpit
Stem
FSA SMR, XS-S:90mm, M-ML:100mm, L-XL:110mm
Handlebar
FSA Trimax Aero, XS-S:40cm, M-ML:42cm, L-XL:44cm
Headset
FSA SSR/ACR 1.5” Integrated
Seat
Saddle
KHS Team Road Cut Out
Seatpost
FSA SLK Carbon 27.2x350
