Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Sora -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum Double Butted w/Disc Mounts and Internal Cable Routing, 1.5 Taper, Flat Mount Disc, fits up 35c tires
Suspension Fork
Full Aluminum Unicrown, Fender Bosses w/Disc, Straight Blade
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
n/a
Shift Levers
Microshift SB-R490, 1x9
Cassette
Shimano HG400-9, 11-34T, 9-Speed
Crank
Samox Aluminum, 36T w/CG, 152mm
Bottom Bracket
FSA Cartridge Bearing
Chain
KMC X9 w/MissingLink
Pedals
Wellgo Full Aluminum, DU Bearings
Wheels
Front Hub
KK Aluminum Disc, QR w/Rubber Seal
Rear Hub
KK Aluminum Disc, QR w/Rubber Seal, Cassette
Rims
Weinmann Aquila 21, Disc, 24”
Spokes
14G Black, 32x32
Tires
Kenda Konversion, 24 x 1.5, Iron Cap, 60TPI
Brakes
Brakes
Bengal MB700T Cable Disc, 140/140, Wave 12
Brake Levers
Microshift SB-R490
Cockpit
Stem
Promax Aluminum 3D Forged, Threadless 4-bolt, 7-degree, 31.8, 60mm
Handlebar
Aluminum Junior Drop, Compact Bend, 31.8 x 36cm
Headset
FSA Integrated Cartridge Bearing
Seat
Saddle
KHS Junior Road Padded
Seatpost
Aluminum Micro-Adjust, 27.2x300mm
