Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Shimano Ultegra Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
KHS Full Carbon GG Design, T700 MSD High Modulus Carbon, 1.5 Taper, 12mm Thru-axle, Flat Mount Disc
Suspension Fork
Full T700 MSD Carbon Disc, 1.5 Taper, 12 x 100mm Thru Axle, Flat Mount, 12mm Thru-axle
Drivetrain
Rear Derailleur
Shimano GRX Gravel RD-RX810
Front Derailleur
Shimano GRX Gravel, FD-RX810
Shift Levers
Shimano GRX Gravel ST-RX600, Hydraulic
Cassette
Shimano CS-HG700, 11-34T, 11-Speed
Crank
FSA Gossamer Pro Compact, 2-pc Forged, BB386, 48/32T, S;170, M-M/L: 172.5, L:175
Bottom Bracket
FSA BB386 EVO Threaded
Chain
KMC X11EL w/MissingLink
Pedals
n/a
Wheels
Front Hub
Formula CL-712, S.B. Super Light Disc, 12mm x 100mm, CenterLock, QR
Rear Hub
Formula RXC-142S, Sealed Bearing Super Light, Cassette, 12x142mm Thru-axle, CenterLock, QR
Rims
WTB ST-I25 TCS, Disc, Double Wall, 32H, Tubeless-Ready
Spokes
14G Stainless Black, 32x32 w/Aluminum Nipples
Tires
Kenda K1226 Alluvium Pro, 700 x 40c, 120TPI, GCT, Folding, Tubeless-Ready
Brakes
Brakes
Shimano New GRX Gravel, BR-RX400 Hydraulic Disc, Flat Mount w/160mm Shimano Freeza Rotors SM-RT800
Brake Levers
Shimano New GRX Gravel ST-RX600 Hydraulic
Cockpit
Stem
FSA Aluminum 3D Forged, Threadless 4-bolt, 31.8mm, S:90mm, M-M/L:100mm, L:110mm
Handlebar
FSA Adventure Compact, Double Butted, Ergonomic, 31.8mm, S:40cm, M-M/L:42cm, L:44cm
Headset
FSA Orbit C40-ACB, N.42/ACB, Angular Contact Bearings, 1-1/8”~1.5” Integrated Aluminum Cap
Seat
Saddle
KHS Sport Road
Seatpost
Q2 Carbon, 27.2mm, 350mm
