Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum w/Custom Formed T/T & D/T w/Replaceable Derailleur Hanger, Internal Cable Routing
Suspension Fork
Aluminum Straight Leg w/CrMo Steerer
Drivetrain
Rear Derailleur
Shimano Cues
Front Derailleur
Shimano Cues, 31.8mm
Shift Levers
Shimano Cues Trigger
Cassette
Shimano CS-HG200-9, 11-36T, 9-Speed
Crank
Shimano FC-MT210-2, 2-pc, 46/30T, 170mm
Bottom Bracket
Shimano Outboard Bearing
Chain
KMC w/MissingLink
Pedals
Wellgo Platform w/Non-slip Tread, DU Bearings
Wheels
Front Hub
Aluminum Disc w/CNC Rotor Flange, QR
Rear Hub
Aluminum Disc w/CNC Rotor Flange, QR, Cassette
Rims
Alex EV-23 Aluminum Double Wall, 26x32H
Spokes
14G Stainless Black, 32x32
Tires
Kenda Khan, 26 x 2.35” w/Anti-Puncture
Brakes
Brakes
Shimano MT200 Hydraulic, 160mm Rotors Wave 12
Brake Levers
Shimano MT200
Cockpit
Stem
Aluminum Threadless, 17 Degree x 80mm
Handlebar
Aluminum, 100mm rise, 660mm
Grips
Comfort Kraton
Headset
1-1/8” Threadless, Zero Stack w/Aluminum Conical Top Cap
Seat
Saddle
DDK Wide Comfort, Memory Foam w/Elastomer Spring
Seatpost
Aluminum Suspension, 27.2x350mm
