Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 120mm -
Travel Rear 110mm -
Fork Fox Performance Float 34
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29” Full MSD Carbon, 4-bar Horst 110mm Travel, 1-1/8~ 1.5 Taper, 12x148mm Boost, 27.5 Plus Compatible
Suspension Fork
FOX Float 34 Step Cast, 29 Std/27.5+ Evol Air, Rhythm, 120mm, Performance Evolair, Grip, 3 POS, Ext Rebound Adjust, 1-1/8~1.5 Taper, 15X110mm QR Boost
Rear Shock
Fox Float DPS, Air, Ext Rebound, Lock-Out, 165x45
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Front Derailleur
n/a
Shift Levers
Shimano SLX, SL-M7100, 12s, Trigger, Right Only, I-Spec EV
Cassette
Shimano CS-M6100, 10-51T, 12-speed
Crank
Shimano FC-MT511, 2-pc, Boost, 32T, S:170, M-L:175
Bottom Bracket
Shimano Outboard Bearing
Chain
Shimano CN-M6100
Pedals
n/a
Wheels
Front Hub
Shimano XT WH-M8100, 15x110mm Boost
Rear Hub
Shimano XT WH-M8100, 12x148mm Boost
Rims
Shimano XT WH-M8100 12S, 29” Disc, Straight Pull, Tubeless-Ready
Spokes
14/15g Black Stainless, w/Aluminum Nipples 28x28
Tires
Kenda Booster Pro, 120TPI Folding, Tubeless-Ready, 29x2.2
Brakes
Brakes
Shimano M6100, Hydraulic Disc, Servo Wave, 180/160mm, RT64 CenterLock Rotors
Brake Levers
Shimano M6100, Servo Wave. I-Spec EV
Cockpit
Stem
FSA V-Drive, 3D Forged, 4-bolt, 6 Degree, 31.8mm, S:60mm, M:70mm, L:80mm
Handlebar
FSA Comet Low Riser, 31.8mm, 15x760mm
Grips
Q2 Lock-on
Headset
FSA Orbit C-40-CF-ACB, N.42/CF/ACB, 1-1/8”~1.5” Integrated
Seat
Saddle
WTB Volt Medium SL
Seatpost
Q2 Carbon, 31.6mmx350mm
