Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Travel Front 40mm -
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TIG-welded Hi-tensile
Suspension Fork
24” Suspension, Aluminum Crown, 40mm Travel
Drivetrain
Rear Derailleur
Shimano Tourney RD-TY300D
Front Derailleur
Shimano Tourney FD-TX800, 28.6mm
Shift Levers
Shimano Revo
Cassette
14-34T, 7-Speed
Crank
Samox Aluminum, 42/34/24T w/Chainguard, 152mm
Bottom Bracket
Cartridge Bearing, 68x118mm
Chain
KMC Z8.3
Pedals
MTB w/ Boron Axle
Wheels
Front Hub
Steel Nutted
Rear Hub
Steel Nutted
Rims
Aluminum, 24”x32H
Spokes
14G Black, 32x32
Tires
24 x 2.10”, Knobby
Brakes
Brakes
Aluminum Linear Pull
Brake Levers
All Aluminum Linear Pull
Cockpit
Stem
Aluminum Threadless 4-bolt, 10 Degree, 60mm
Handlebar
Aluminum 30mm Rise, 600mm
Grips
Soft Kraton
Headset
Threadless 1-1/8”
Seat
Saddle
Ultracycle Junior
Seatpost
Aluminum Micro-Adjust 25.4x300mm
