Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Sora -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum, TIG welded w/Disc Tab, 12 x 148 Thru-axle
Suspension Fork
Oversized CrMo Unicrown, 1.5 Taper, 12 x 110 Thru-axle
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora, 31.8mm
Shift Levers
Shimano Sora Trigger
Cassette
Shimano HG400-9, 11-34T, 9-Speed
Crank
Driveline 2-pc Aluminum Forged Tandem; Stoker: 50/39/30T + 39T, 170mm; Captain: 39T, 175mm
Bottom Bracket
Outboard Cartridge Bearing
Chain
KMC Z9 w/MissingLink
Pedals
n/a
Wheels
Front Hub
Powerway 12x110 Thru-axle, Sealed Bearing, Disc
Rear Hub
Powerway 12x148 Thru-axle, Cassette. Sealed Bearing, Disc
Rims
WTB STI 25 (27.5) Disc, Double Wall, Tubeless-Ready
Spokes
14G Black, 40x40
Tires
WTB Byway 650B x 47mm
Brakes
Brakes
Bengal MB700, Mechanical Disc, 220mm Rotors
Brake Levers
Promax Aluminum Linear Pull
Cockpit
Stem
Captain: Threadless 3D Forged, 25D, 31.8mm, 90mm, Stoker: Aluminum, 35 Degree Adjustable
Handlebar
F: Aluminum Riser 680x35x31.8mm, R: Aluminum Riser, 580x100x25.4mm
Grips
KHS Sport Dual Compound
Headset
FSA Orbit 1.5E ZS, 1-1/8”~1.5”, Aluminum Cap
Seat
Saddle
KHS Road Padded & Ladies Road Padded with Handles
Seatpost
Captain: Aluminum Micro Adjust, 27.2x350, Stoker: Aluminum Suspension, Micro Adjust, 27.2x300mm
