Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Groupset Alivio, Sora -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 520, Double Butted CrMo
Suspension Fork
Full CrMo w/ Disc & Rack Bosses
Drivetrain
Rear Derailleur
Shimano Alivio RD-M3100
Front Derailleur
Shimano Sora FD-R3030, 31.8mm
Shift Levers
Shimano Sora STI, STR3030/3000
Cassette
Shimano HG200-9, 11-36T, 9-Speed
Crank
Shimano Sora FCR-3030, 2-pc Forged, 50/39/30T, XS:165, S:170, M-L:175
Bottom Bracket
Shimano Outboard Bearing
Chain
KMC X9 w/MissingLink
Pedals
n/a
Wheels
Front Hub
Shimano HB-M4050, QR
Rear Hub
Shimano FH-M4050 Cassette, QR
Rims
Weinmann Aluminum XC-180 Disc, Double wall
Spokes
14G Stainless Black, 36x36
Tires
Kenda Kwick Journey 700 x 40c, 60TPI, w/K-Shield Anti-Puncture
Brakes
Brakes
Bengal MB700T Cable Disc, 160mm Wave ‘12’
Brake Levers
Shimano Sora STI, STR3030/3000
Cockpit
Stem
Aluminum 3D Forged, Threadless 4-bolt, 31.8mm, XS-S:90mm, M:100mm, L: 110mm
Handlebar
FSA Vero Compact, Aluminum Double Butted, 31.8mm, XS-M:42cm, L:44cm
Headset
FSA Threadless 1-1/8”, 15mm Top Cap
Seat
Saddle
WTB Rocket V Sport
Seatpost
Aluminum Suspension Micro-Adjust, 27.2x350mm
