Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork SunTour RAIDON 32
-
Groupset SLX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New KHS Full MSD Carbon 29er w/1.5 Taper Headtube, Disc Only, Internal Cable Routing, 12X148 Boost, 27.5 Plus & 29 Plus Compatible
Suspension Fork
SR Raidon 32-LOR, 29 Std/27.5 Plus, 100mm Air, Hydraulic Speed Lock-Out w/Ext. Rebound Damping Adj, 1-1/8~ 1.5 Alloy Taper, 15Q x 110 Boost
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano SLX RD-M7000
Front Derailleur
n/a
Shift Levers
Shimano SLX, SL-M7000, 11s, Trigger, Right Only
Cassette
Sun Race, 11-46T, 11-speed
Crank
Samox 2pc Forged, PF92, Narrow Wide 32T, Boost, 175
Bottom Bracket
PF92
Chain
KMC X11EL-1 w/Missing Link
Pedals
N/A
Wheels
Rims
WTB STP-i23 TCS, Disc, Double Wall, 29x28H, Tubeless Ready
Spokes
14G Stainless Black w/Alloy Nipples, 28X28
Tires
Maxxis Ikon EXO/TR, 60TPI Folding, Tubeless Ready, 29X2.2
Brakes
Brakes
Shimano M396 Hydraulic Disc,180/160mm Rotors Wave 12
Brake Levers
Shimano M396
Cockpit
Stem
Alloy 3D Forged, 4-bolt, 6 Degree, 31.8, M-L: 80mm, XL: 90mm
Handlebar
Alloy Butted Low Riser, 31.8, 720X12mm
Headset
FSA Orbit C-40-CF-ACB, N.42/CF/ACB, 1-1/8"~1.5" Integrated
Seat
Saddle
WTB Volt Sport
Seatpost
KHS Alloy Micro-adjust, 31.6X350mm
About this model
TUCSON completes the Khs Tucson model. KHS launched 12 bikes of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2018 for 2399$. Doing a quick comparison, we notice that TUCSON price is 25.93% higher than the average cost of a Crosscountry bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
This bike has the SunTour RAIDON 32 fork installed. The fork’s travel is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, KHS TUCSON 2018, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike has one size only, so it might not fit you. In short, make sure you double-check if it fits you.
