Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Zoom
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum with C/S Disc Mount, w/Replaceable Derailleur Hanger, Internal Cable
Suspension Fork
Zoom 565D, 80mm Travel
Drivetrain
Rear Derailleur
Shimano RD-TY300
Front Derailleur
Shimano FD-TY601, 34.9mm
Shift Levers
Shimano ST-EF500
Cassette
Shimano Cassette, CS-HG20-7, 12-32T, 7-Speed
Crank
Shimano FC-TY-301, 48/38/28T, S: 170mm, M-XXL: 175mm
Bottom Bracket
FSA Cartridge Bearing, 122.5mm
Chain
KMC Z8.3
Pedals
Resin ATB Platform w/Boron Axle
Wheels
Front Hub
KT Aluminum Disc w/CNC Rotor Flange, QR
Rear Hub
KT Aluminum Disc w/CNC Rotor Flange, QR, Cassette
Rims
Aluminum, 700c x 32H, Double wall
Spokes
14G Black, 32x32
Tires
Kenda Happy Medium, 700 x 40c, 30TPI
Brakes
Brakes
Radius Cable Disc BR-CX7, 160mm Rotors w/ABS System Click for more information about BrakeSafe
Brake Levers
Shimano ST-EF500
Cockpit
Stem
KHS Aluminum Threadless 4-bolt, 6-degree, 31.8mm, S:60mm, M-L:75mm, XL-XXL:90mm, Ladies: S:60mm, M:75mm
Handlebar
Aluminum, 31.8mm, 680x20mm, Ladies: 660x20mm
Grips
KHS Sport, Dual Compound
Headset
Threadless 1-1/8”, ZeroStack
Seat
Saddle
KHS Sport
Seatpost
KHS Aluminum Micro-Adjust, 31.6x350mm
