Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour XCE
-
Groupset Tourney, Acera -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum w/Custom Formed T/T & DT with C/S Disc Mount, w/Replaceable Derailleur Hanger, Internal Cable
Suspension Fork
SR XCE28, 80mm Travel
Drivetrain
Rear Derailleur
Shimano Acera M3020
Front Derailleur
Shimano FD-TY606, 34.9mm
Shift Levers
Shimano SL-M315 Trigger
Cassette
Shimano CS-HG400-8, 11-40T, 8-Speed
Crank
Shimano FC-TY-501, 46/30T, S: 170mm, M-XXL: 175mm
Bottom Bracket
Cartridge Bearing, 122.5mm
Chain
KMC Z8.3
Pedals
Resin ATB Platform w/DU Bearings
Wheels
Front Hub
KT Aluminum Disc w/CNC Rotor Flange, QR
Rear Hub
KT Aluminum Disc w/CNC Rotor Flange, QR, Cassette
Rims
Aluminum, 700c x 32H, Double wall
Spokes
14G Black, 32x32
Tires
Kenda Happy Medium, 700 x 40c, 30TPI
Brakes
Brakes
Bengal Cable Disc, MB606, 160mm Rotors Wave 12 w/ABS System Click for more information about BrakeSafe
Brake Levers
Promax All Aluminum Linear Pull
Cockpit
Stem
KHS Aluminum Threadless 4-bolt, 6-degree, 31.8mm, S:60mm, M-L:75mm, XL-XXL:90mm, Ladies: S:60mm, M:75mm
Handlebar
Aluminum, 31.8mm, 680x20mm, Ladies: 660x20mm
Grips
KHS Sport Lock-on
Headset
Threadless 1-1/8”, ZeroStack
Seat
Saddle
KHS Sport
Seatpost
KHS Aluminum Micro-Adjust, 31.6x350mm
