Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour NVX
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum w/Custom Formed T/T & DT with C/S Disc Mount, w/Replaceable Derailleur Hanger, Internal Cable
Suspension Fork
SR NVX NLO, w/Hydraulic Lock-Out, 80mm, Preload Adjust
Drivetrain
Rear Derailleur
Shimano Cues
Front Derailleur
Shimano Acera Cues, 34.9mm
Shift Levers
Shimano Acera Cues Trigger
Cassette
Shimano CS-HG300-9 11-36T, 9-Speed
Crank
Shimano Cues, 46/30T, 2-pc, S: 170mm, M-XL: 175mm
Bottom Bracket
Shimano Outboard Cartridge Bearing
Chain
KMC w/MissingLink
Pedals
Wellgo Aluminum Platform w/DU Bearings
Wheels
Front Hub
KT Aluminum Disc w/CNC Rotor Flange, QR
Rear Hub
KT Aluminum Disc w/CNC Rotor Flange, QR, Cassette
Rims
Aluminum, 700c x 32H, Double wall
Spokes
14G Stainless Black, 32x32
Tires
Kenda Happy Medium, 700 x 40c, 30TPI
Brakes
Brakes
Bengal Ares 3, Hydraulic Disc, 160mm Rotors Wave 12
Brake Levers
Bengal Ares 3
Cockpit
Stem
KHS Aluminum Threadless 4-bolt, 6-degree, 31.8mm, S:60mm, M-L:75mm, XL:90mm, Ladies:75mm
Handlebar
Aluminum Riser, 31.8mm, 680x20mm, Ladies: 660x20mm
Grips
KHS Sport Lock-on
Headset
Threadless 1-1/8”, ZeroStack
Seat
Saddle
KHS Sport
Seatpost
KHS Aluminum Micro-Adjust, 31.6x350mm
