Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Groupset Tourney -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TIG-Welded Hi-Tensile Steel w/Carrier Bosses
Suspension Fork
High Tensile Straight Blades
Drivetrain
Rear Derailleur
Shimano RD-TX800
Front Derailleur
n/a
Shift Levers
MicroShift TS71-8 Trigger
Cassette
Shimano CS-HG200-8, 12-32T, 8-Speed
Crank
Aluminum Forged, 3-pc, 44T w/Aluminum Double Guard, 170mm
Bottom Bracket
FSA Cartridge Bearing, 118mm
Chain
KMC Z8.3
Pedals
Resin Platform w/Boron Axle
Wheels
Front Hub
Aluminum QR
Rear Hub
Aluminum QR, Cassette, Cassette
Rims
Deep Dish Aluminum, Double Wall, 700x32H
Spokes
14G Stainless Black, 32x32
Tires
Kenda Kwest, 700 x 28c
Brakes
Brakes
Aluminum Dual Pivot, Long Reach
Brake Levers
Aluminum 2 Finger
Cockpit
Stem
Aluminum Threadless 4-bolt, 15 Degree, S: 70mm, M-L:80mm, XL: 90mm
Handlebar
Aluminum 20mm Rise, 600mm, 10 Degree
Grips
Q2 Lock-On
Headset
Threadless 1-1/8”
Seat
Saddle
KHS Road Padded
Seatpost
Aluminum Micro-Adjust, 26.0x350mm
