Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 Double Butted CrMo Tubing and Carrier Bosses, Forged Disc Mount, Internal Cables
Suspension Fork
Hi-Tensile Unicrown Straight Blade, 1-1/4" Tapered
Drivetrain
Rear Derailleur
Shimano Altus, M310
Front Derailleur
Shimano FD-TY710, 28.6x350mm
Shift Levers
Microshift TS71Z, 3x8
Cassette
Shimano CS-HG318, 11-34T, 8-Speed
Crank
Shimano FC-TY301, 48/38/28T w/CG, S-M:170, L-XL:175
Bottom Bracket
FSA Cartridge Bearing, 122.5mm
Chain
KMC Z8.3
Pedals
Wellgo Full Aluminum w/DU Bearing
Wheels
Front Hub
KT Aluminum Disc, QR w/Rubber Seal
Rear Hub
KT Aluminum Disc, QR w/Rubber Seal, Cassette
Rims
Weinmann Aluminum U28, Disc Double Wall, 27.5x32H
Spokes
14G Stainless Black, 32x32
Tires
WTB Byway, 27.5 x 47mm
Brakes
Brakes
Bengal Aries 3,Hydraulic Disc, 160mm Wave 12 Rotors
Brake Levers
Bengal Aries 3
Cockpit
Stem
KHS Aluminum Threadless, 25D, 4-bolt, S: 80mm, M-L:90mm, XL: 100mm
Handlebar
Aluminum Trekking, 630mm, 31.8mm
Grips
Q2 Ergo Lock-On, Dual Density
Headset
Threadless 1-1/8”, Zero Stack
Seat
Saddle
KHS Ultra Comfort, Soft Shell
Seatpost
Aluminum Micro-Adjust, 27.2mm
