Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Promax Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 Double Butted CrMo Tubing and Carrier Bosses, Forged Disc Mount, Internal cables
Suspension Fork
Hi-Tensile Unicrown, Straight Blade
Drivetrain
Rear Derailleur
Shimano Altus, M310
Front Derailleur
Shimano, FD-TY710, 28.6mm
Shift Levers
Microshift TS71 Triggers, 3x8
Cassette
Shimano CS-HG31-8, 11-34T, 8-Speed
Crank
Shimano FC-TY301, 48/38/28T w/Chainguard, S-M:170, L-XXL:175
Bottom Bracket
Cartridge Bearing
Chain
KMC Z8.3
Pedals
Wellgo Platform w/Non-slip Tread, DU Bearings
Wheels
Front Hub
KK Aluminum, QR, w/Rubber Seal
Rear Hub
KK Aluminum, QR, w/Rubber Seal, Cassette
Rims
Weinmann XTB26, 700x32H, Double Wall w/CNC Side Wall
Spokes
14G Stainless Black, 32x32
Tires
Kenda Keen, 700 x 35c w/K-Shield
Brakes
Brakes
Promax Aluminum Linear Pull, w/ABS System
Brake Levers
Promax Aluminum Linear Pull Trekking, 3 Finger
Cockpit
Stem
KHS Aluminum Threadless, 25D, 4-bolt, S:80mm, M-L:90mm, XL:100mm, XXL: 110mm
Handlebar
Aluminum Trekking, 630mm, 31.8mm
Grips
Q2 Ergo Lock-On, Dual Density
Headset
Threadless 1-1/8”, Zero Stack
Seat
Saddle
KHS Ultra Comfort, Soft Shell
Seatpost
Aluminum Micro-Adjust, 27.2mm
