Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Groupset CUES -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Tektro Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 520 DB CrMo Tubing w/Carrier Bosses, Internal Cables
Suspension Fork
Full CrMo Unicrown, Low-rider and Fender Bosses, Straight Blade
Drivetrain
Rear Derailleur
Shimano Cues
Front Derailleur
MicroShift FD-T392B, 28.6mm
Shift Levers
Shimano Cues, 2x9 Triggers
Cassette
Shimano CS-HG200-9, 11-36T, 9-Speed
Crank
FSA Tempo, 48/32T, S:170, M-L: 172.5, XL-XXL: 175
Bottom Bracket
FSA Cartridge Bearing, 124.5mm
Chain
KMC w/MissingLink
Pedals
Wellgo Full Aluminum w/Non-Slip Tread, DU Bearings
Wheels
Front Hub
KK Aluminum, QR, w/Rubber Seal
Rear Hub
KK Aluminum, QR, w/Rubber Seal, Cassette
Rims
Weinmann XTB26, 700x32H, Double Wall w/CNC Side Wall
Spokes
14G Stainless Black, 32x32
Tires
Kenda Kwick Journey, 700 x 35c w/K-Shield Anti-Puncture, 60TPI
Brakes
Brakes
Tektro 855AL, Aluminum Linear Pull, Long Reach, w/ABS System Click for more information about BrakeSafe
Brake Levers
Promax Aluminum Forged Trekking, Knee Saver
Cockpit
Stem
KHS Aluminum Threadless, 25D, 4-bolt, S:80mm, M-L:90mm, XL:100mm, XXL: 110mm
Handlebar
Aluminum Trekking, 630mm, 31.8mm
Grips
Q2 Ergo Lock-On, Dual Density
Headset
Threadless 1-1/8”, ZeroStack
Seat
Saddle
KHS Ultra Comfort Plus, Soft Shell w/Memory Foam
Seatpost
Aluminum Micro-Adjust, 27.2x350mm
