Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum w/Custom Formed Double Butted T/T & D/T, Bi-Oval Pro Seat Stays, Internal Cable, Disc, Replaceable Derailleur Hanger
Suspension Fork
Carbon w/Aluminum Steerer
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Microshift FD-R352B, 31.8mm
Shift Levers
Microshift SL-R769-2 Trigger
Cassette
Shimano CS-HG400-9, 11-34T, 9-Speed
Crank
Aluminum Forged 2-pc, 50/34T Compact, S:170mm, M-XXL:175mm
Bottom Bracket
Outboard Cartridge Bearing
Chain
KMC Z99 w/MissingLink
Pedals
Wellgo 1-pc Full Aluminum w/DU Bearing
Wheels
Front Hub
KT Aluminum Disc, QR
Rear Hub
KT Aluminum Disc, QR, Cassette
Rims
Weinmann Aquila 21, 700c, Double wall disc
Spokes
14G stainless Black, 24x28
Tires
Kenda Kwick Roller, 700 x 32c w/Anti-Puncture, 60TPI, Folding
Brakes
Brakes
Bengal Aries 3 Hydraulic Disc, 160x160, Wave ‘12’
Brake Levers
Bengal Aries 3
Cockpit
Stem
KHS Aluminum 3D Forged, Threadless 4-bolt, 7-degree, 31.8mm, S:80mm, M-L:90mm, XL-XXL:100mm
Handlebar
Aluminum Riser 620x20mm, 31.8mm
Grips
Velo Silicone Foam
Headset
Integrated Cartridge Bearing
Seat
Saddle
KHS Fitness Padded
Seatpost
KHS Aluminum Micro-Adjust, 27.2x350mm
