Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour XCE
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum, TIG welded, Internal Cables
Suspension Fork
SR XCE28, 80mm Travel
Drivetrain
Rear Derailleur
Shimano Tourney, RD-TY300D
Front Derailleur
Shimano Tourney, TY510, 31.8mm
Shift Levers
Shimano, ST-EF510
Cassette
Shimano Mega Range, 14-34T, 7-Speed
Crank
Shimano FC-TY501, 48/38/28T w/Chainguard, 170mm
Bottom Bracket
Cartridge Bearing
Chain
KMC Z8.3
Pedals
Platform w/Non-slip Tread, DU Bearings
Wheels
Front Hub
Aluminum, QR, Rubber Seal
Rear Hub
Aluminum, QR, Rubber Seal
Rims
Weinmann Aluminum, 700c, 32H
Spokes
14G Stainless, 32x32
Tires
Kenda Khan, 700 x 38c, Skin Wall w/Anti-Puncture
Brakes
Brakes
Aluminum Linear Pull w/ABS System
Brake Levers
Shimano ST-EF510
Cockpit
Stem
Aluminum Quill, 25 Degree, S=80mm, M-XL=100mm
Handlebar
Aluminum, 100mm rise, 660mm
Grips
Comfort Kraton
Headset
1-1/8” Threaded, Zero Stack w/Aluminum Conical Top Cap
Seat
Saddle
DDK Wide Comfort, Memory Foam w/Elastomer Spring
Seatpost
Aluminum Suspension, 27.2x350mm
