Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset S-Ride -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum w/Custom Formed T/T & D/T, w/Replaceable Derailleur Hanger, XS-S:27.5”, M-XL:29”, Internal Cable Routing
Suspension Fork
SR XCT30, HLO. 100mm, Hydraulic Lock-Out, Preload Adjust XS-S:27.5”, M-XL:29”
Drivetrain
Rear Derailleur
S-Ride RD-M300C, 9-Speed
Front Derailleur
n/a
Shift Levers
S-Ride SL-M300C, 9-Speed
Cassette
CS-M300C 11-42T, 9-Speed
Crank
Samox Forged, 30T Narrow/Wide, XS-S:170, M-XL:175
Bottom Bracket
Cartridge Bearing
Chain
KMC X9 w/MissingLink
Pedals
Resin ATB Platform w/DU Bearings
Wheels
Front Hub
Aluminum Disc w/CNC Rotor Flange, QR
Rear Hub
Aluminum Disc w/CNC Rotor Flange, QR, Cassette
Rims
Aluminum Disc Double Wall, XS-S: 27.5x32H, M-XL: 29x32H
Spokes
14G Black 32x32
Tires
Kenda Saber, XS-S: 27.5x2.2, M-XL: 29x2.2
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180/160mm Rotors Wave 12
Brake Levers
Shimano MT200
Cockpit
Stem
Aluminum Threadless 4-bolt, 6-degree, 31.8, XS:60mm, S-M:75mm, L-XL:90mm
Handlebar
KHS Aluminum Riser, 31.8, 720x20mm, Ladies:680x20mm
Grips
KHS Sport
Headset
Threadless ZeroStack, 1-1/8"
Seat
Saddle
KHS Sport
Seatpost
KHS Aluminum Micro-Adjust 31.6x350
