Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum w/Custom Formed T/T & D/T w/C/S Disc Mount, w/Replaceable Derailleur Hanger
Suspension Fork
Carbon w/Aluminum Steerer
Drivetrain
Rear Derailleur
Shimano Cues
Front Derailleur
Shimano Cues, 34.9mm
Shift Levers
Shimano Cues, 9-Speed
Cassette
Shimano Cues 11-36T, 9-Speed
Crank
Shimano, 46/30T, 2-pc, XS-S: 170, M-XL: 175
Bottom Bracket
Shimano Outboard Cartridge Bearing
Chain
KMC w/MissingLink
Pedals
Wellgo Platform w/Non-slip Tread, DU Bearings
Wheels
Front Hub
KK Aluminum Disc, QR w/Rubber Seal
Rear Hub
KK Aluminum Disc, QR w/Rubber Seal, Cassette
Rims
Weinmann U26 Disc, 700x32H, Double Wall
Spokes
14G Stainless Black, 32x32
Tires
Kenda Kwick Bitumen K1068, 700 x 40c
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 160mm Rotors Wave 12
Brake Levers
Shimano MT201
Cockpit
Stem
KHS Aluminum Threadless, 17D, 4-bolt, XS:80mm, S-L: 90mm, XL: 100mm
Handlebar
Aluminum Trekking, 630mm, 31.8mm
Grips
Q2 Ergo Lock-On, Dual Density
Headset
Threadless 1-1/8”, ZeroStack
Seat
Saddle
KHS Ultra Comfort Plus, Soft Shell w/Memory Foam
Seatpost
KHS Aluminum Micro-Adjust, 31.6x350mm
