Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 80mm -
Fork Zoom
-
Groupset S-Ride -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum w/Custom Formed T/T & D/T, w/Replaceable Derailleur Hanger, XS-S:27.5”, M-XL:29”, Internal Cable Routing
Suspension Fork
Zoom 565D, 80mm, XS-S:27.5”, M-XL:29”
Drivetrain
Rear Derailleur
Ride RD-M300C, 8-Speed
Front Derailleur
n/a
Shift Levers
S-Ride SL-M300C, 8-Speed
Cassette
S-Ride CS-M20008 11-42T, 8-Speed
Crank
Samox Forged, 30T Narrow/Wide C/R, XS-S:170, M-XL:175
Bottom Bracket
Cartridge Bearing
Chain
KMC Z8.3
Pedals
Resin ATB Platform w/DU Bearings
Wheels
Front Hub
Aluminum Disc w/CNC Rotor Flange, QR
Rear Hub
Aluminum Disc w/CNC Rotor Flange, QR, Cassette
Rims
Aluminum Disc Double Wall, XS-S: 27.5x32H, M-XL: 29x32H
Spokes
14G Black 32x32
Tires
Kenda Saber, XS-S: 27.5x2.2, M-XL: 29x2.2
Brakes
Brakes
Radius Cable Disc BR-CX7, 180/160mm Rotors w/ABS System
Brake Levers
Aluminum Linear Pull, 2.5F
Cockpit
Stem
Aluminum Threadless 4-bolt, 6-degree, 31.8, XS-S:60mm, M-L:75mm, XL:90mm
Handlebar
Aluminum Riser, 31.8, 720x20mm, Ladies:680mm
Grips
KHS Sport
Headset
Threadless Zero Stack, 1-1/8
Seat
Saddle
KHS Sport
Seatpost
KHS Aluminum Micro-Adjust 31.6x350mm
