Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 138mm -
Fork Marzocchi Bomber Z1
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM Slack
155cm - 171cm
SM Neutral
155cm - 171cm
MD Slack
169cm - 179cm
MD Neutral
169cm - 179cm
LG Slack
177cm - 189cm
LG Neutral
177cm - 189cm
XL Slack
187cm - 195cm
XL Neutral
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6066 Aluminum, Custom Titanium Hardware
Suspension Fork
Marzocchi Z1 29” 150mm 44mm Offset
Rear Shock
Fox Float X Performance
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle
Cassette
SRAM XG1275 Eagle 10-52T
Crank
SRAM GX Eagle 170 32T Ring
Bottom Bracket
SRAM DUB BSA SB+
Chain
SRAM GX Eagle
Wheels
Rims
RaceFace Aeffect R 30 Trace 28h J-Bend (XD) OR DT Swiss M1900 SPLINE 28h Straight-Pull (XD)
Tires
Front: Maxxis DHF 29" 2.5" 3C Maxx Terra EXO, Rear: Maxxis DHR2 29" 2.3" 3C Maxx Terra EXO
Brakes
Brakes
Magura MT5
Cockpit
Stem
Spank 35mm x 40mm
Handlebar
Spank 35mm x 800mm, 25mm Rise
Grips
Spank / SDG
Headset
FSA Orbit ZS44/56
Seat
Saddle
SDG Bel-Air V3
Seatpost
SDG Tellis 170mm, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM Slack | SM Neutral | MD Slack | MD Neutral | LG Slack | LG Neutral | XL Slack | XL Neutral |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.451 mm | 1.451 mm | 1.366 mm | 1.366 mm | 1.313 mm | 1.313 mm | 1.274 mm | 1.274 mm |
| Bottom Bracket Height | 326 mm | 335 mm | 326 mm | 335 mm | 326 mm | 335 mm | 326 mm | 335 mm |
| Front Center | 757 mm | 757 mm | 784 mm | 784 mm | 810 mm | 810 mm | 836 mm | 836 mm |
| Rake | 44 mm | 50 mm | 44 mm | 50 mm | 44 mm | 50 mm | 43 mm | 49 mm |
| Trail | 126 mm | 114 mm | 126 mm | 114 mm | 126 mm | 114 mm | 127 mm | 115 mm |
| Stack | 631 mm | 631 mm | 631 mm | 631 mm | 637 mm | 637 mm | 647 mm | 647 mm |
| Reach | 435 mm | 435 mm | 462 mm | 462 mm | 485 mm | 485 mm | 508 mm | 508 mm |
| Top Tube Length | 574 mm | 574 mm | 608 mm | 608 mm | 641 mm | 641 mm | 672 mm | 672 mm |
| Seat Tube Angle | 76 ° | 76.7 ° | 76 ° | 76.7 ° | 76 ° | 76.7 ° | 76 ° | 76.7 ° |
| Seat Tube Length | 355 mm | 355 mm | 400 mm | 400 mm | 456 mm | 456 mm | 500 mm | 500 mm |
| Head Tube Angle | 65 ° | 65.75 ° | 65 ° | 65.75 ° | 65 ° | 65.75 ° | 65 ° | 65.75 ° |
| Head Tube Length | 108 mm | 108 mm | 108 mm | 108 mm | 115 mm | 115 mm | 125 mm | 125 mm |
| Chainstay Length | 432 mm | 430 mm | 432 mm | 430 mm | 432 mm | 430 mm | 432 mm | 430 mm |
| Wheelbase | 1185 mm | 1185 mm | 1212 mm | 1212 mm | 1238 mm | 1238 mm | 1264 mm | 1264 mm |
| Bottom Bracket Drop | 48 mm | 39 mm | 48 mm | 39 mm | 48 mm | 39 mm | 48 mm | 39 mm |
| Standover Height | 690 mm | 690 mm | 718 mm | 718 mm | 769 mm | 769 mm | 782 mm | 782 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 155 cm | 169 cm | 169 cm | 177 cm | 177 cm | 187 cm | 187 cm |
| Rider Max Height | 171 cm | 171 cm | 179 cm | 179 cm | 189 cm | 189 cm | 195 cm | 195 cm |
