Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 150mm -
Travel Rear 160mm -
Fork Fox Float 32
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Scandium Butted 100 -160mm travel
Suspension Fork
FOX 32 Talas RL 150mm w/15mm TA
Rear Shock
Fox Float RP23
Drivetrain
Rear Derailleur
Shimano Deore XT Shadow SGS
Front Derailleur
Shimano SLX
Shift Levers
Shimano SLX
Cassette
Shimano SLX 11-34 10 spd
Crank
42/32/24
Bottom Bracket
Shimano
Chain
Shimano SLX
Pedals
Shimano M520 Clipless
Wheels
Front Hub
Mavic Crossride Disc Wheelset
Rear Hub
Mavic Crossride Disc Wheelset
Rims
Mavic Crossride Disc Wheelset
Spokes
Mavic Crossride Disc Wheelset
Tires
Maxxis Ardent 26x2.25 Kevlar
Brakes
Brakes
Avid Elixir 5
Brake Levers
Avid Elixir 5
Disk Rotors
Avid G3 Clean Sweep 185mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
FSA No.57E
Seat
Saddle
WTB Valcon Comp
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 366 | 40.6cm | 43.2cm | 45.7cm | 48.3cm | 50.8cm | 55.9cm |
|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm | 353 mm |
| Front Center | 682 mm | 707 mm | 720 mm | 733 mm | 736 mm | 759 mm | 784 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Top Tube Length | 559 mm | 584 mm | 597 mm | 610 mm | 622 mm | 635 mm | 660 mm |
| Seat Tube Angle | 74.8 ° | 74.8 ° | 74.8 ° | 74.8 ° | 74.8 ° | 74.8 ° | 74.8 ° |
| Seat Tube Length | 366 mm | 406 mm | 432 mm | 457 mm | 483 mm | 508 mm | 559 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 125 mm | 130 mm | 130 mm | 135 mm | 135 mm | 140 mm | 145 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1112 mm | 1137 mm | 1150 mm | 1164 mm | 1167 mm | 1189 mm | 1213 mm |
| Bottom Bracket Drop | -10 mm | -10 mm | -10 mm | -10 mm | -10 mm | -10 mm | -10 mm |
| Standover Height | 748 mm | 764 mm | 777 mm | 791 mm | 804 mm | 819 mm | 846 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
About this model
CADABRA completes the Kona Cadabra model. There are 4 bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
CADABRA components
Fork
The fork installed on this bike is the Fox Float 32 model. The travel on this model is 150mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The CADABRA has a rear shock with a travel of 160mm. The model Fox Float RP23 is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Kona CADABRA 2011, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
When you want to stop the bike in time, the brakes are vital. The CADABRA has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
