Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona All-Mountain Aluminum Butted
Suspension Fork
RockShox Tora SL Solo 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT Shadow
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore
Cassette
Shimano HG50 (11-32, 9spd)
Crank
44/32/22
Bottom Bracket
FSA MegaExo
Chain
KMC HG53
Pedals
Shimano M505 Clipless
Wheels
Front Hub
Formula Disc
Rear Hub
Shimano M475 Disc
Rims
Alex DP17
Spokes
Sandvik Stainless 15g fr/14g rr
Tires
Maxxis Aspen 26 x 2.1
Brakes
Brakes
Shimano 575 Disc 7" fr / 6" rr
Brake Levers
Shimano 575 Disc
Cockpit
Stem
Kona XC/BC (14-16=75, 17-19=90, 20-22=105mm)
Handlebar
Kona XC/BC Riser (660mm Wide)
Grips
Kona Race Light
Headset
TH
Seat
Saddle
WTB Rocket V Comp
Seatpost
Kona XC/BC
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 356 | 40.6cm | 43.2cm | 45.7cm | 48.3cm | 50.8cm | 55.9cm |
|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 311 mm | 311 mm | 314 mm | 314 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 622 mm | 634 mm | 642 mm | 654 mm | 657 mm | 672 mm | 696 mm |
| Rake | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Top Tube Length | 558 mm | 571 mm | 585 mm | 596 mm | 609 mm | 622 mm | 647 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.6 ° | 70.6 ° | 70.6 ° | 70.1 ° |
| Seat Tube Length | 356 mm | 406 mm | 432 mm | 457 mm | 483 mm | 508 mm | 559 mm |
| Head Tube Angle | 68 ° | 68 ° | 68.5 ° | 68.6 ° | 68.6 ° | 68.6 ° | 68.6 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm | 125 mm | 140 mm | 160 mm | 175 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1053 mm | 1064 mm | 1073 mm | 1085 mm | 1090 mm | 1104 mm | 1124 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 29 mm | 29 mm | 26 mm | 26 mm | 26 mm |
| Standover Height | 741 mm | 763 mm | 776 mm | 787 mm | 806 mm | 827 mm | 856 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
CALDERA completes the Kona Caldera model. Kona launched 3 bikes of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
Kona CALDERA 2010 bike is equipped with the RockShox fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Kona CALDERA 2010, has a 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona CALDERA has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
