Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset XT, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 7005 Aluminum Butted
Suspension Fork
Rockshox Recon TK Solo Air 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT Shadow SGS
Front Derailleur
Shimano Alivio
Shift Levers
Shimano Deore
Cassette
Shimano HG50 11-34 9 spd
Crank
44/32/22
Bottom Bracket
FSA MegaExo
Chain
Shimano HG53
Pedals
Shimano M505 Clipless
Wheels
Front Hub
Shimano M435 Disc
Rear Hub
Shimano M435 Disc
Rims
Mavic XM119
Spokes
Sandvik Stainless 15g fr / 14g rr
Tires
Maxxis Aspen 26x2.1
Brakes
Brakes
Shimano new Deore BR-M596
Brake Levers
Shimano Deore BR-M596
Disk Rotors
Avid G3 Clean Sweep 185mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light
Headset
FSA
Seat
Saddle
WTB Valcon Sport SE
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 17" | 18" | 19" | 20" | 22" |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.38 mm | 1.37 mm | 1.42 mm | 1.4 mm | 1.38 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 310 mm | 310 mm | 310 mm | 310 mm | 315 mm |
| Front Center | 635 mm | 665 mm | 675 mm | 685 mm | 690 mm | 700 | 725 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Stack | 556 mm | 601 mm | 581 mm | 591 mm | 606 mm | 611 mm | 621 mm |
| Reach | 391 mm | 411 mm | 421 mm | 431 mm | 426 mm | 436 mm | 451 mm |
| Top Tube Length | 566 mm | 591 mm | 601 mm | 616 mm | 626 mm | 641 mm | 666 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 71.5 ° | 71.5 ° | 71 ° |
| Seat Tube Length | 355 mm | 405 mm | 430 mm | 455 mm | 485 mm | 510 mm | 560 mm |
| Head Tube Angle | 68 ° | 68 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 140 mm | 155 mm | 165 mm | 180 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1061 mm | 1086 mm | 1096 mm | 1111 mm | 1111 mm | 1126 mm | 1151 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 33 mm | 33 mm | 33 mm | 33 mm | 28 mm |
| Standover Height | 736 mm | 756 mm | 776 mm | 791 mm | 811 mm | 826 mm | 861 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
Caldera is a Kona Caldera model. Kona launched 3 bikes of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Caldera components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Caldera model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Caldera comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
