Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork RockShox Recon Silver TK
-
Groupset SLX, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
RockShox Recon Silver TK 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano SLX
Front Derailleur
Shimano Alivio
Shift Levers
Shimano Alivio
Cassette
Shimano HG50 11-32t 9 spd
Crank
42/34/24t
Bottom Bracket
Shimano ES25
Chain
KMC HG53
Pedals
Wellgo LUA9
Wheels
Front Hub
Formula
Rear Hub
Shimano M475
Rims
Mavic XM11
Spokes
Stainless 15g fr / 14g rr
Tires
Vittoria Saguaro 26x2.0"
Brakes
Brakes
Avid Elixir 1
Brake Levers
Avid Elixir 1
Disk Rotors
Avid G2 180mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light
Headset
TH ZST No.10
Seat
Saddle
WTB Volt Sport
Seatpost
Kona Thumb
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 17" | 18" | 19" | 20" | 22" |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.38 mm | 1.37 mm | 1.42 mm | 1.4 mm | 1.38 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 310 mm | 310 mm | 310 mm | 310 mm | 315 mm |
| Front Center | 635 mm | 665 mm | 675 mm | 685 mm | 690 mm | 700 | 725 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 98 mm | 111 mm | 96 mm | 95 mm | 95 mm | 93 mm | 89 mm |
| Stack | 556 mm | 601 mm | 581 mm | 591 mm | 606 mm | 611 mm | 621 mm |
| Reach | 391 mm | 411 mm | 421 mm | 431 mm | 426 mm | 436 mm | 451 mm |
| Top Tube Length | 566 mm | 591 mm | 601 mm | 616 mm | 626 mm | 641 mm | 666 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 71.5 ° | 71.5 ° | 71 ° |
| Seat Tube Length | 355 mm | 405 mm | 430 mm | 455 mm | 485 mm | 510 mm | 560 mm |
| Head Tube Angle | 68 ° | 68 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 140 mm | 155 mm | 165 mm | 180 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1061 mm | 1086 mm | 1096 mm | 1111 mm | 1111 mm | 1126 mm | 1151 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 25 mm | 25 mm | 25 mm | 25 mm | 20 mm |
| Standover Height | 736 mm | 756 mm | 776 mm | 791 mm | 811 mm | 826 mm | 861 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
CINDER CONE completes the Kona Cinder model. There are 13 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
CINDER CONE components
Fork
The fork installed on this bike is the RockShox Recon Silver TK model. The travel on this model is 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The CINDER CONE 2013 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The CINDER CONE comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
