Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset SLX, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Scandium
Suspension Fork
RockShox 30 Gold 100mm
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano SLX
Front Derailleur
Shimano Alivio
Shift Levers
Shimano Alivio
Cassette
Shimano HG20 11-34t 9 spd
Crank
22/33/44t
Bottom Bracket
Shimano ES25
Chain
KMC X9
Chain Guide
n/a
Pedals
Wellgo Platform
Wheels
Front Hub
Joytech
Rear Hub
Joytech
Rims
WTB SX19
Spokes
Sandvik Stainless 15g fr / 14g rr
Tires
Maxxis Ardent 27.5x2.25"
Brakes
Brakes
Shimano M446 Hydraulic
Brake Levers
Shimano M505 Hydraulic
Disk Rotors
Shimano 180mm
Cockpit
Stem
Kona XC/Road
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light
Headset
TH ZST No.10
Seat
Saddle
WTB Volt Sport
Seatpost
Kona Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17" | 19" | 21" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.46 mm | 1.43 mm | 1.41 mm |
| Bottom Bracket Height | 306 mm | 306 mm | 306 mm | 306 mm |
| Front Center | 646 mm | 672 mm | 698 mm | 725 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 90 mm | 91 mm | 91 mm | 91 mm |
| Stack | 589 mm | 599 mm | 617 mm | 636 mm |
| Reach | 389 mm | 411 mm | 431 mm | 450 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 646 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | mm | 533 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 115 mm | 135 mm | 155 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1065 mm | 1090 mm | 1117 mm | 1143 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm | 49 mm |
| Standover Height | 752 mm | 780 mm | 812 mm | 844 mm |
| Wheels | 27" | 27" | 27" | 27" |
Model Overview
CINDER CONE completes the Kona Cinder model. 13 bikes variations carry this model name so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The CINDER CONE comes factory-installed with the RockShox 30 Silver TK fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on CINDER CONE are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The CINDER CONE has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
