Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 154cm
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 6061 Aluminum Butted
Suspension Fork
RockShox 30 Gold RL Solo Air 100mm
Rear Shock
n/a
Drivetrain
Rear Derailleur
SRAM NX
Front Derailleur
n/a
Shift Levers
SRAM NX
Cassette
SRAM PG1130 11-42t 11spd
Crank
SRAM NX, 30t Narrow/Wide
Bottom Bracket
SRAM Powerspline 73mm
Chain
SRAM PC1110
Chain Guide
n/a
Pedals
Kona JS2
Wheels
Front Hub
Formula 100x9mm (centerlock)
Rear Hub
Shimano 135x10mm (centerlock)
Rims
WTB STP i25
Spokes
Stainless Black 15g fr / 14g rr
Tires
Schwalbe Nobby Nic 27.5/26x2.25"
Brakes
Brakes
Shimano Hydraulic MT500
Brake Levers
Shimano Hydraulic MT500
Disk Rotors
Shimano RT30 180mm (centerlock)
Cockpit
Stem
Kona XC
Handlebar
Kona XC/BC Riser
Grips
Kona Key Grip Slip on
Headset
FSA No.57B
Seat
Saddle
WTB Volt Sport SE (Volt 250 Sport SE size S)
Seatpost
Kona Thumb w/Offset 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.41 mm | 1.35 mm | 1.3 mm |
| Bottom Bracket Height | 303 mm | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 652 mm | 660 mm | 691 mm | 719 mm | 754 mm |
| Rake | 39 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 102 mm | 95 mm | 95 mm | 95 mm | 94 mm |
| Stack | 558 mm | 586 mm | 600 mm | 609 mm | 623 mm |
| Reach | 394 mm | 401 mm | 426 mm | 450 mm | 480 mm |
| Top Tube Length | 554 mm | 569 mm | 598 mm | 625 mm | 659 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 331 mm | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 68 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 100 mm | 115 mm | 125 mm | 140 mm |
| Chainstay Length | 424 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1074 mm | 1090 mm | 1120 mm | 1148 mm | 1184 mm |
| Bottom Bracket Drop | 30 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 676 mm | 714 mm | 724 mm | 729 mm | 749 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 154 cm | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
Cinder Cone is part of the Kona Cinder model. Kona launched 13 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Kona released this model in 2018, its price was 1199$. If we compare this with the average Crosscountry bike cost we notice that the price is 58.88% smaller.
Cinder Cone components
Fork
The fork installed on this bike is the RockShox 30 Silver TK model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the Cinder Cone model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Cinder Cone has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Kona Cinder Cone bike has 5 sizes, in the range of 147 cm – 195 cm (4.82 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
