Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 180mm -
Travel Rear 200mm -
Fork Fox Float 36
-
Groupset X9, SLX -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Clump Butted Aluminum Butted 120-200mm travel
Suspension Fork
Fox 36 Talas R 180mm w/20mm TA
Rear Shock
Fox Float RP2 w/BSD
Drivetrain
Rear Derailleur
SRAM X9 SGS
Front Derailleur
Shimano SLX
Shift Levers
SRAM X5
Cassette
SRAM PG 1030 11-36 10 spd
Crank
E*13/36/24
Bottom Bracket
FSA MegaExo
Chain
SRAM PC-1031
Pedals
Kona Wah Wah
Wheels
Front Hub
Easton Vice Disc Wheelset 20mm
Rear Hub
Easton Vice Disc Wheelset 12mm
Rims
Easton Vice Disc Wheelset
Spokes
Easton Vice Disc Wheelset
Tires
Maxxis Ardent 26x2.4
Brakes
Brakes
Avid Code R
Brake Levers
Avid Code R
Disk Rotors
Avid HS1 200mm
Cockpit
Stem
Kona XC/BC
Handlebar
Kona XC/OB Riser
Grips
Kona G-LOG
Headset
FSA No.57B
Seat
Saddle
WTB Valcon Comp
Seatpost
Kona Primo Double Clamp w/offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 17" | 18" | 19" | 20" | 22" |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.51 mm | 1.46 mm | 1.43 mm | 1.41 mm | 1.36 mm | 1.3 mm |
| Bottom Bracket Height | 360 mm | 360 mm | 360 mm | 360 mm | 360 mm | 360 mm | 360 mm |
| Front Center | 695 mm | 720 mm | 735 mm | 745 mm | 760 mm | 770 mm | 800 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Stack | 589 mm | 594 mm | 599 mm | 599 mm | 604 mm | 604 mm | 609 mm |
| Reach | 374 mm | 394 mm | 409 mm | 419 mm | 429 mm | 444 mm | 469 mm |
| Top Tube Length | 559 mm | 584 mm | 594 mm | 609 mm | 619 mm | 634 mm | 659 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 365 mm | 405 mm | 430 mm | 455 mm | 485 mm | 510 mm | 560 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 125 mm | 130 mm | 135 mm | 135 mm | 140 mm | 140 mm | 145 mm |
| Chainstay Length | 479 mm | 479 mm | 479 mm | 479 mm | 479 mm | 479 mm | 479 mm |
| Wheelbase | 1144 mm | 1164 mm | 1179 mm | 1194 mm | 1204 mm | 1219 mm | 1244 mm |
| Bottom Bracket Drop | -17 mm | -17 mm | -17 mm | -17 mm | -17 mm | -17 mm | -17 mm |
| Standover Height | 789 mm | 799 mm | 809 mm | 819 mm | 829 mm | 839 mm | 854 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
Model Overview
CoilAir is a Kona Coilair model. There are 5 bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Downhill bikes average price
If you want an acceptable Downhill bike you should know that the average price is 3391$. However, even if your budget is less than the average, you might still be able to get a top-quality Downhill bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The Fox Float 36 is included from the factory. It has a travel distance of 180mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Kona CoilAir bike has the Fox Float RP2 w/BSD model installed, and has a travel of 200mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on CoilAir are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
