Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 26" -
Travel Front 80mm -
Fork Marzocchi
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Mechanical Disc
Sizing
Recommended size guide.
LG
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Clump Cromoly Butted
Suspension Fork
Marzocchi DJ Comp 80mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Formula 14T
Crank
Aricle 30T
Bottom Bracket
Chainway Spanish BB
Chain
KMC Z410B
Pedals
Wellgo B107.P
Wheels
Front Hub
Formula Disc 20mm
Rear Hub
Formula Disc 135mm
Rims
Alex MUS30
Spokes
Stainless 14g
Tires
Maxxis Holy Roller 26x2.4
Brakes
Brakes
ProMax Mechanical Disc
Brake Levers
ProMax Mechanical Disc
Disk Rotors
ProMax 160mm
Cockpit
Stem
Kona DH
Handlebar
Kona DJ Bar
Grips
Kona DJ
Headset
FSA
Seat
Saddle
Kona Pivotal
Seatpost
Pivotal
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | R | LG |
|---|---|---|
| Stack Reach Ratio | 1.363 mm | 1.313 mm |
| Bottom Bracket Height | 310 mm | 310 mm |
| Front Center | 655 mm | 665 mm |
| Rake | 50 mm | 50 mm |
| Stack | 545 mm | 545 mm |
| Reach | 400 mm | 415 mm |
| Top Tube Length | 585 mm | 595 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° |
| Head Tube Angle | 69 ° | 69 ° |
| Head Tube Length | 115 mm | 115 mm |
| Chainstay Length | 400 mm | 400 mm |
| Wheelbase | 1050 mm | 1065 mm |
| Bottom Bracket Drop | 33 mm | 33 mm |
| Standover Height | 725 mm | 725 mm |
| Wheels | 26" | 26" |
Model Overview
Downside is a Kona Downside model. 3 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The Marzocchi is included from the factory. It has a travel distance of 80mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the Downside model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Downside has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
