Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Seamless 3-2.5 Titanium
Suspension Fork
Fork
Drivetrain
Rear Derailleur
rd
Front Derailleur
fd
Shift Levers
Shifters
Cassette
Freewheel
Crank
Chainrings
Bottom Bracket
bb
Chain
Chain
Pedals
Pedals
Wheels
Front Hub
fronthub
Rear Hub
rearhub
Rims
Rims
Spokes
Spokes
Tires
fronttire
Brakes
Brakes
brakecalipers
Brake Levers
brakelevers
Disk Rotors
frontbrakerotor
Cockpit
Stem
Stem
Handlebar
Handlebar
Grips
Grips
Headset
Headset
Seat
Saddle
Saddle
Seatpost
Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.49 mm | 1.52 mm | 1.55 mm | 1.56 mm | 1.58 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 262 mm | 262 mm | 264 mm | 264 mm |
| Front Center | 581 mm | 583 mm | 593 mm | 603 mm | 614 mm | 622 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 70 mm | 65 mm | 64 mm | 64 mm | 61 mm | 58 mm |
| Stack | 542 mm | 565 mm | 582 mm | 601 mm | 620 mm | 641 mm |
| Reach | 376 mm | 380 mm | 384 mm | 388 mm | 397 mm | 405 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72.5 ° | 73 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm | 225 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm | 426 mm | 426 mm |
| Wheelbase | 992 mm | 994 mm | 1005 mm | 1015 mm | 1029 mm | 1038 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 74 mm | 74 mm | 72 mm | 72 mm |
| Standover Height | 745 mm | 770 mm | 790 mm | 805 mm | 825 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
About this model
ESATTO TI completes the Kona Esatto model. There are 15 bikes that carry this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Wheels
When leaving the production line, the ESATTO TI model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
ESATTO TI comes in 6 sizes, that range from 155 cm – 191 cm (5.09 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
