Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCR 32
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 154cm
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Suntour XCR 32 LO-R Coil Spring 100mm
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus
Cassette
Shimano HG200 11-36t 9spd
Crank
Shimano Altus, 22/36t
Bottom Bracket
Shimano 73mm
Chain
KMC X9
Chain Guide
n/a
Pedals
Kona JS2
Wheels
Front Hub
Formula 100x9mm
Rear Hub
Formula 135x10mm
Rims
Alex DP25
Spokes
Stainless Black 14g
Tires
WTB Trail Boss 27.5/26x2.25"
Brakes
Brakes
Tektro HDM275 Hydraulic
Brake Levers
Tektro HDM275 Hydraulic
Disk Rotors
Tektro TR180 180mm
Cockpit
Stem
Kona Control
Handlebar
Kona Aluminum Riser
Grips
Kona Key Grip Slip on
Headset
FSA No.57B
Seat
Saddle
Kona XC
Seatpost
Kona Thumb w/Offset 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.41 mm | 1.36 mm | 1.31 mm | 1.24 mm |
| Bottom Bracket Height | 303 mm | 304 mm | 304 mm | 304 mm | 304 mm |
| Front Center | 662 mm | 678 mm | 709 mm | 737 mm | 778 mm |
| Rake | 40 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 104 mm | 98 mm | 98 mm | 98 mm | 98 mm |
| Stack | 555 mm | 584 mm | 598 mm | 607 mm | 621 mm |
| Reach | 399 mm | 414 mm | 439 mm | 464 mm | 499 mm |
| Top Tube Length | 548 mm | 571 mm | 599 mm | 627 mm | 666 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 331 mm | 370 mm | 420 mm | 470 mm | 530 mm |
| Head Tube Angle | 67.5 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 100 mm | 115 mm | 125 mm | 140 mm |
| Chainstay Length | 424 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1084 mm | 1108 mm | 1138 mm | 1167 mm | 1207 mm |
| Bottom Bracket Drop | 30 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 674 mm | 709 mm | 717 mm | 723 mm | 746 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 154 cm | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
Fire Mountain is part of the Kona Fire model. 15 bikes variations carry this model name so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 749$. If we compare this with the average Crosscountry bike cost we notice that the price is 154.34% smaller.
Overview of components
Fork
Kona Fire Mountain 2020 bike is equipped with the SunTour XCR 32 fork, and has 100mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on Fire Mountain are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Kona Fire Mountain has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Fire Mountain comes in 5 sizes, that range from 147 cm – 195 cm (4.82 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
