Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Revelation RC
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Cromoly Butted
Suspension Fork
RockShox Revelation RL Solo Air 120mm QR15 Tapered
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus
Front Derailleur
n/a
Shift Levers
Shimano Deore (rh only)
Cassette
Shimano Deore 11-36t 10spd
Crank
32t Narrow/Wide
Bottom Bracket
RaceFace
Chain
KMC X10
Pedals
n/a
Wheels
Front Hub
Shimano Deore QR15
Rear Hub
Shimano Deore 142x12mm
Rims
WTB ST i23 TCS
Spokes
Stainless 14g
Tires
Maxxis Ardent EXO TR 29x2.4"
Brakes
Brakes
Shimano Deore
Brake Levers
Shimano Deore
Disk Rotors
Shimano SLX 180mm (centerlock)
Cockpit
Stem
Kona XC/BC
Handlebar
Kona XC/BC Riser
Grips
Kona S-LOG
Headset
FSA Orbit 1.5 ZS NO.57
Seat
Saddle
WTB Volt Comp
Seatpost
Kona OB
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.5 mm | 1.43 mm | 1.37 mm |
| Bottom Bracket Height | 309 mm | 309 mm | 309 mm | 309 mm |
| Front Center | 690 mm | 716 mm | 741 mm | 765 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 102 mm | 102 mm | 103 mm | 102 mm |
| Stack | 635 mm | 640 mm | 645 mm | 649 mm |
| Reach | 404 mm | 428 mm | 452 mm | 474 mm |
| Top Tube Length | 582 mm | 608 mm | 633 mm | 657 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 478 mm | 508 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 110 mm | 115 mm | 120 mm |
| Chainstay Length | 413 mm | 413 mm | 413 mm | 413 mm |
| Wheelbase | 1095 mm | 1121 mm | 1146 mm | 1170 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 753 mm | 753 mm | 758 mm | 758 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
Model Overview
HONZO is part of the Kona Honzo model. Kona launched 53 bikes of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the HONZO bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Kona HONZO is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
HONZO comes in 4 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
