Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Shimano -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona 6061 Aluminum Butted
Suspension Fork
Kona Project Two JR
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano
Front Derailleur
n/a
Shift Levers
Shimano Revo Shift
Cassette
Shimano TZ 14-34t 7spd
Crank
Samox 152mm, 28t/Guard
Bottom Bracket
Shimano 68mm
Chain
KMC HV500
Chain Guide
n/a
Pedals
Feimin Platform
Wheels
Front Hub
Joytech 100x9mm
Rear Hub
Joytech 135x10mm
Rims
Double Wall alloy
Spokes
Stainless 14g
Tires
Front: Vee Tire Crown Gem 24x2.6", Rear: Vee Tire Crown Gem 24x2.6"
Brakes
Brakes
Tektro V-Brake
Brake Levers
Tektro Junior
Cockpit
Stem
Kona Control
Handlebar
Kona Riser
Grips
Velo Junior
Headset
Feimin FP-H863
Seat
Saddle
Kona Junior
Seatpost
Kona Thumb 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM |
|---|---|
| Stack Reach Ratio | 1.383 mm |
| Bottom Bracket Height | 285 mm |
| Front Center | 582 mm |
| Rake | 45 mm |
| Stack | 495 mm |
| Reach | 358 mm |
| Top Tube Length | 500 mm |
| Seat Tube Angle | 74 ° |
| Seat Tube Length | 295 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 420 mm |
| Wheelbase | 1008 mm |
| Bottom Bracket Drop | 40 mm |
| Standover Height | 615 mm |
| Wheels | 24" |
