Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Sektor
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light 6061 Aluminum Butted 120mm Travel
Suspension Fork
RockShox Sektor TK Solo Air Tapered 130mm
Rear Shock
RockShox Monarch RL
Drivetrain
Rear Derailleur
Shimano XT
Front Derailleur
Shimano SLX
Shift Levers
Shimano Deore
Cassette
Shimano HG62 11-36t 10 spd
Crank
42/32/24
Bottom Bracket
Shimano BB51
Chain
Shimano HG54
Pedals
Shimano M505 Clipless
Wheels
Front Hub
Shimano SLX
Rear Hub
Shimano SLX
Rims
WTB STi23 TCS
Spokes
Sandvik Stainless Double Butted 14g fr / 15g rr
Tires
Maxxis Ardent 26x2.25" Folding
Brakes
Brakes
Shimano Deore
Brake Levers
Shimano Deore
Disk Rotors
Shimano 180mm
Cockpit
Stem
Kona XC/Road Deluxe
Handlebar
Kona XC/BC Riser
Grips
Kona Race Light LOG
Headset
FSA No.57B
Seat
Saddle
WTB Volt Comp
Seatpost
Kona Double Clamp Deluxe w/Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.366 mm | 1.326 mm | 1.275 mm | 1.229 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 680 mm | 705 mm | 730 mm | 705 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 94 mm | 89 mm | 93 mm | 147 mm |
| Stack | 560 mm | 570 mm | 580 mm | 590 mm |
| Reach | 410 mm | 430 mm | 455 mm | 480 mm |
| Top Tube Length | 570 mm | 595 mm | 620 mm | 650 |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1100 mm | 1130 mm | 1155 mm | 1130 mm |
| Standover Height | 790 mm | 795 mm | 800 mm | 805 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 152 cm | 157 cm | 175 cm | 180 cm |
| Rider Max Height | 170 cm | 182 cm | 195 cm | 195 cm |
About this model
KITSUNE completes the Kona Kitsune model. There is 1 bike that carries this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
KITSUNE components
Fork
The RockShox Sektor is included from the factory. It has a travel distance of 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Monarch RL model, with a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the KITSUNE bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
KITSUNE comes in 4 sizes, that range from 152 cm – 195 cm (4.99 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
